Renewable energy for desalination: An interview with HE Dr Abdulrahman Al-Ibrahim

Solar desalination plant in Saudi Arabia
The Kingdom of Saudi Arabia has the most installed capacity for desalination in the world and currently it is planning to export its technical know-how regionally and internationally. Image: Power Insider Asia

This feature news is part of Singapore International Water Week’s (SIWW) series of one-on-one interviews with global water industry leaders, Conversations with Water Leaders. In this edition, HE Dr Abdulrahman M Al-Ibrahim, Governor of Saline Water Conversion Corporation (SWCC), Kingdom of Saudi Arabia, shares with OOSKAnews correspondent, Renee Martin-Nagle, his thoughts on renewable energy for desalination and the provision of water for all.

HE Dr Abdulrahman M Al-Ibrahim elaborates on how he combined desalination with renewable energy, SWCC’s strive towards operational excellence, environmental responsibility and more.

To start, would you mind speaking about the focus that is being placed by Saudi Arabia on solar energy for desalination?

Certainly. Recently the SWCC board of directors adopted a series of strategic goals, one of which is operational excellence. Part of that operational excellence is to enrich our portfolio of energies, including renewable energies like solar, photovoltaic, thermal, wind, geothermal, and other renewable energies. In the recent past we initiated construction of the first solar desalination plant in Al-Khafji that will produce 30,000 cubic meters per day of desalinated water and is operated by photovoltaic cells with an RO [reverse osmosis] desalination system. The King Abdulaziz City for Science and Technology (KACST) was the leader of this program, and we partnered with KACST to build, manage and maintain the plant throughout its life. We are investigating a more rigorous program to produce around 300,000 cubic metres per day with renewable energies. So, to summarize, renewable energy is not a luxury for us.  It is part of our strategy, and it is a means to enrich our portfolio of energy so that we will have the right mix for our operation.

My understanding is that the energy output of solar may not be adequate for some of the older desal technologies such as multi-stage flash.  Is that why you are using it for reverse osmosis?

I’m sure if we want to couple renewable energy with desalination, we will have to look at different technologies and pick the ones that are the best match, which could be Multi-Effect Distillation (MED), RO hybrid or Tri-hybrid. To start with, we selected RO for the Al-Khafji plant because as a rule of thumb, RO requires the least energy, but on the west coast we are investigating other technologies, such as Tri-hybrid. It’s partially an MED as well as an RO plant with Nano-Filtration (NF) and other means. We are devoting R&D to finding the right technologies to adapt to the renewable energies available locally.

All the projects I am currently overseeing are my favorite, but I’ll tell you about my dream. My dream is to have a highly reliable and very efficient desalination plant that becomes a model not just for our kingdom, Saudi Arabia, but a model worldwide.

Saudi Arabia has the most installed capacity for desalination in the world.  As you do research and gather technologies, does the Kingdom intend to become an exporter of technology as well as an importer?

Yes, we do. For the past 30 or 40 years, the ultimate goal of SWCC was to produce desalinated water to meet the needs of the Kingdom. Now we want to go beyond that goal and export know-how regionally as well as internationally. Our roadmap is to be able to develop know-how, intellectual property, prototypes and patents locally. In the past three or four years, we have come to own some patents, and we want to double that number in the next couple of years.

Would you give me an example of the latest technologies that you are exploring?

Sure. SWCC, together with the Water Re-use Promotion Center of Japan and Sasakura Company, conducted a joint research study to develop a fully integrated NF/SWRO/MED tri-hybrid system. This desalination system enabled us to reduce significantly the water production cost per unit, which we see as a break-through. Subsequently, a number of patents have been registered in Saudi Arabia, Japan and China.

How did you personally get involved in desalination?

I’m a graduate of the mechanical engineering program in Jeddah, in the area of thermal science, and at that time, we were required to study two courses in desalination and do two internships in industrial facilities. My second internship was in a small Multi-Stage Flash (MSF) plant in Jeddah, and, after doing a research project, it became my dream to combine desal with renewable energy. Luckily, in around 1986, I also worked with a very small solar desalination plant in Yanbu that used a technology called thermal freezing, where you freeze the seawater using an absorption system to reach almost zero degrees and then recover fresh water from the system. I went on to get a Master’s degree and a PhD in thermal engineering and renewable energies, and moved my expertise to energy efficiency. After 20 or 30 years, combining desal and renewable energy is becoming a reality instead of a pilot.

What changes have you seen in the past 20-25 years since you first got involved with desal?

Almost two months ago we launched a new plant in Jeddah called Jeddah RO-3 that operates on reverse osmosis. This plant was built on a site where a thermal plant was in operation since the late 70s and produced 40,000 cubic metres. We demolished the old plant and built a new one on the same footprint that now produces 240,000 cubic metres. So in a 25- or 30-year span we were able to increase production by six times over.

The second thing is our local expertise here in Saudi Arabia. In the past, we had to hire multiple international companies to be able to operate our plants and produce the water. In those days, you would seldom find a Saudi person operating or maintaining the plant.  Now, Saudi locals perform 91 per cent of all our operations as engineers, technicians and managers who understand the technologies and who are able to diagnose and fix problems. We admire and respect all international expertise and we utilize it to the best that we can. At the same time, we feel that we are ready now to stretch our arms to regional and international markets and spread our expertise in terms of technologies, IP and manufacturing facilities. The Kingdom of Saudi Arabia has invested in desal, and we hope that it will add value to our GDP.

What will be the criteria for choosing desal technologies in the future?

Two factors will be the criteria for selecting technology — energy consumption and reliability. Membrane technology will be able to attain energy efficiency very well. However, we need to be able to assist it with more devices to make it more reliable. If the price of energy is important in your area, then you need to give it more weight. If reliability is more of an issue, then you give it more weight.

As much as we care about producing water, we also care about the environment, for multiple reasons. The primary factor is that we live in and share the same area, so we need to protect the environment next to us.  Secondly, our intake is affected by its surrounding area, and therefore we should not spoil the water next to the plant itself.

What is the problem with membrane reliability?

Membrane technology is very sensitive to the quality of water it receives. For example, if there is red tide, or an algae bloom, or any other material in the seawater, such as a high Silt Density Index (SDI), you would need to shut down the plant to preserve your membrane, or augment your plant with pre-treatment facilities to clean the water before you introduce it to the membrane. On the other hand, although thermal is very expensive and utilizes maybe two or three times as much energy as membrane technology, it may tolerate any water. Also, to be able to build membrane technology, you need to have a pilot plant for a year or two at the same location and study the water carefully to select the most appropriate pre-treatment process.

SWCC uses seawater for its operations.  What you do with the brine that is left over?

As much as we care about producing water, we also care about the environment, for multiple reasons. The primary factor is that we live in and share the same area, so we need to protect the environment next to us.  Secondly, our intake is affected by its surrounding area, and therefore we should not spoil the water next to the plant itself. We perform multiple procedures so as not to intervene with the eco-system next to the plant. We do this at SWCC and in any saline water industrial facility. For example, one standard procedure is to withdraw up to ten times the amount of water that you intend to desalinate, and discharge the extra with the brine to reduce the effect of high temperature or high salinity. We also measure the temperature of the intake and the discharged brine to make sure we protect the ecosystem next to the plant.

The newly commissioned plant in Jeddah – the Jeddah RO-3 – was built with multiple advanced measures to protect the environment –not only water intake and the brine but also energy efficiency within the building. We reduced the energy consumption through the cooling grade and the lighting system, and we are applying to multiple professional organizations to receive certificates of energy efficiency in the new building as well as in the plant.

There is a desalination plant that is constructed on a floating platform in Yanbu.  Would you describe it?

It’s one of the unique features that we have in Saudi Arabia. We have two barges, each one able to produce 25,000 cubic metres per day, that move on the west coast from Yanbu to Shuaibah to Shuqaiq or anywhere else to augment the production of a desal plant. So we move the barge from one location to the other according to the needs that may occur. The barges are stand-alone, with their own power supplied by liquid fuel.

I always hesitate to ask a parent which of his children is the favorite, but would you tell me if there are any projects that are your favorite?

All the projects I am currently overseeing are my favorite, but I’ll tell you about my dream. My dream is to have a highly reliable and very efficient desalination plant that becomes a model not just for our kingdom, Saudi Arabia, but a model worldwide. I want it to become a benchmark.

What final message would you like to leave with our readers?

The people of Saudi Arabia and the employees of the Saline Water Conversion Corporation are eager to produce water to serve the needs of anyone who lives on the planet earth. And we’re extremely happy to share our technologies and information with anyone who shares the same interest values. We believe, as the people of Saudi Arabia, that water is a commodity that should be made available to anyone who lives on the planet, regardless of his faith, regardless of his type, whether he’s human or animal or anyone else. The commercial aspect is an instrument to enable us to provide water that is necessary for life on earth. I totally believe that water is a value-related issue. It’s not a luxury item that needs to be looked at from a commercial business point of view. It’s something that has to be made available for everyone, so that anyone who lives on earth will have adequate quantity and quality of water.
